Description
The Ampere Audio AA-3.0 10″ is the most torture tested subwoofers in the Ampere Audio lineup. The Ampere Audio AA-3.0 10″ was designed for 2000w rms per driver. The lead wires are formed into the spider layers which further enhances durability and eliminates lead slap/breakage problems. The frame is cast aluminum with a sandblasted, powder coat finish. One of the thickest 3” coils on the motor reduces energy storage from inductance, with the side benefit of lowering distortion for “faster” response.
Ampere Audio AA-3.0 10″ D4 Technical Specs
View AllClose
Ampere Audio AA-3.0 10″ D4 Technical Specs
- 2000w RMS
- Triple stacked 1″ slugs
- 4 layer 3″ aluminum coil
- 3 Layer spider pack
- Sewn leads
- Pressed paper cone
- Butyl rubber surround
- D2 or D4
- RE (Ohms): 4 / 6.8
- FS (Hz): 39.2 / 40.4
- VAS (L): 10.9 / 9.5
- Qes: 0.897 / 0.802
- Qms: 3.079 / 2.73
- Qts: 0.569 / 0.62
- BL (NA): 18.51 / 22.16
- Mms (Grams): 210.49 / 228.22
- Cms (MM/N): 77.91 / 67.97
- Sens (dB @ 1w/1m): 81.7 / 80.8
- Sealed Enclosure: Not Recommended
- Ported Enclosure: 1.5 cu ft
- Recommended Tuning: 32Hz
- Recommended Port Area: 24 sq in
- Displacement: 0.21 cu ft
- Depth:
- Outside Diameter: 10.5
- Cut-Out: 9.46
1 Review
-
AA 3.0 v4 10s
Beastly subs, and I haven't even gave them enough power yet.
