DC Audio
DC Audio 250.4 - 4 Channel amplifier
- SKU:
- DC250.4
- Weight:
- 22.00 LBS
- Shipping:
- Calculated at Checkout
Description
Amplifier Description
The 250.4 competition series amplifier is a Monster Class D 4 Channel Amplifier Delivering 250 watts per channel @ 4 ohms / 400 watts x 4 @ 2 ohms per channel or 850 watts x2 @ 4 ohms bridged. It is not 1 ohm stable.
Output Power (RMS)
4 ohm 250Wx4 @ 14.4 Volts
2 ohm 400Wx4 @ 14.4 Volts
4 ohm mono 850Wx2 @ 14.4 Volts
1700 watts total power
Key Features
Variable high pass filter with X10 option
Variable low pass filter with X10 option
Bandpass Filter Capable
8awg Speaker Connections
1/0 awg inputs
Tiffany RCA Jacks
Class D
8-16 Volts Operations
Remote Control with Clipping LED’s
Heatsink Clipping LED’s for Channels 1&2 / 3&4
AMP SPECS:
| DC Amp Model: | 250.4 |
|---|---|
| Input Sensitivity | 6V~0.2V |
| Working Voltage | 8vdc-16vdc |
| 12dB / Octave Crossover | YES |
| High Pass | 20(200)Hz - 800(8K)Hz, x10 muliply |
| Low Pass | 50(500)Hz - 800(8K)Hz, x10 muliply |
| Crossover Selector Switch | HPF / FULL / LP / BP |
| Remote Control | Yes with Clipping Led |
| Signal to Noise Ratio | dB95 |
| Damping Factor | 130< |
| THD @ 4ohms | Less than 0.1% |
| Fuse Rating | External 200 amp |
| LED Status Lights | Power/Protect/Clipping |
| Heatsink Length | 13.78"/350mm |
| Heatsink Width | 9.38"/66mm |
| Heatsink Heigth | 2.35"/59.6mm |
