Incriminator Audio I304 300w RMS 4 Channel Amplifier

The 2016 I Series amplifiers is Incriminator Audio's first line of entry amplifiers. The I Series models have been designed from the ground up to be a more affordable solution, while still having all of the features that you have come to expect from our IA Series amplifiers, from remotes and strapping to more flexible crossover networks.

Features

• Full Range Class A/B Amplifier
• Dual MOS-FET Pulse Width Modulation Power Supply
• 2 Ohm Stable Stereo / 4 Ohm Mono Topology / 16 Volt Stable
• Extremely High Tolerance Electrical Components For Reliability
• Proprietary Custom Tooled Heatsink
• Black Molded Oversized 4 AWG Power and Ground Inputs
• Multi-Layer Bullet Proof Protection Circuit
• Remote Bass
• 1 Year Limited Warranty

Specifications

• Rated Power ( 14.4V at 1% THD )
• RMS Power - 4 Ohm Mono : 150W x 2CH
• RMS Power - 2 Ohm Stereo : 75W x 4CH
• RMS Power - 4 Ohm Stereo : 50W x 4CH
• Low Pass Filter ( 12dB/Oct. ) : 50Hz - 5000Hz ( X1, X10 )
• High Pass Filter ( 12dB/Oct. ) : 10Hz – 100Hz
• Subsonic Filter ( 12dB/Oct. ) : 10Hz - 500Hz
• Frequency Response ( +/-1dB ) : 20Hz - 20,000Hz
• Channel Separation : 60dB
• Input Sensitivity ( Volt +/- 5% ) : 6.0V - 0.2V
• Signal / Noise Ratio : 95dB
• Dampening Factor ( 4 Ohm ) : 200 +
• Operation Mode : Mirror CH1/2 > CH3/4
• Power Efficiency ( 4 Ohm ) : 65%
• Fuse Rating ( 14.4V ) : 40A
• Power Input Connection : 4 Gauge
• Operation Voltage : 10V - 16.0V
• Speaker Output Connection : 8 Gauge
• Dimensions ( Inches ) : 6.85 W x 2.36 H x 12.20 L
• Dimensions ( Millimeters ) : 174 W x 60 H x 310 L
