US Acoustics "Mai" Class D 5 Channel Amplifier

(No reviews yet) Write a Review
SKU:
USACOU-MAI
Availability:
Ships within 1 - 2 Business Days
Weight:
12.00 LBS
Shipping:
Calculated at Checkout
  • US Acoustics "Mai" 5 Channel Amplifier | USACOU-MAI | in Amplifiers | Brand US Acoustics
  • US Acoustics "Mai" 5 Channel Amplifier | USACOU-MAI | in Amplifiers | Brand US Acoustics
  • US Acoustics "Mai" 5 Channel Amplifier | USACOU-MAI | in Amplifiers | Brand US Acoustics
  • US Acoustics "Mai" 5 Channel Amplifier | USACOU-MAI | in Amplifiers | Brand US Acoustics
  • US Acoustics "Mai" 5 Channel Amplifier | USACOU-MAI | in Amplifiers | Brand US Acoustics
  • US Acoustics "Mai" 5 Channel Amplifier | USACOU-MAI | in Amplifiers | Brand US Acoustics
1800woofers Price $399.00

Description

Features:
  • 4 x 50 Watts RMS @ 4 Ohm
  • Compact Design for Smaller Installation Footprint
  • Angled Terminals for show quality installations
  • Full Range Class D Design
  • Conformal Coated Printed Circuit Board for Marine and Motorcycle Applications
  • DC, Short Circuit, Thermal and Overload Protection
  • Diagnostic LEDs
Specs:
  • OUTPUT POWER @ 14.4V input
  • DAMPING FACTOR: @100Hz 4 ohm: > 100
  • RMS per channel at 4 Ohms: 50 W x 4 CH
  • RMS per channel at 2 Ohms: 80 W x 4 CH
  • RMS Bridged Mono at 4 Ohms: 160 W x 2 CH
  • RMS Mono at 1 Ohm: 300 W x 1 CH
  • INPUT SENSITIVITY: 200mV - 6.0V
  • FREQUENCY RESPONSE: 10Hz - 22KHz +/- 0.5dB
  • THD: LESS THAN 0.5%
  • S/N RATIO: > 96 dB
  • CHANNEL SEPARATION: > 70 dB
  • DAMPING FACTOR @100Hz 4 ohm: > 100
  • CROSSOVER RANGE: CH 3&4, CH 1&2
  • High Pass, 12dB/Octave: 20 Hz - 3K Hz, Ch 1 & 2; 15 Hz - 1.5K Hz, CH 3 & 4
  • Low Pass, 24dB/Octave: 50 Hz - 5K Hz, CH 3 & 4
  • Low Pass, 24dB/Octave: 50 Hz - 500 Hz, CH 5
  • Variable Bass Boost: No
  • Wired remote bass control included: No
  • Phase Shift (0 - 180 degrees): No
  • Fusing: 1 x 70A
  • Size: (L x W x H) in 11.41 x 4.68 x 2.04
    • Download Specs Here
